C6P – An ninh Mắt cá 360° Không lo điểm mù

C6P – An ninh Mắt cá 360° Không lo điểm mù

Sản phẩm này đã hết hàng hoặc không có sẵn.

Thông số kỹ thuật

C6P

An ninh Mắt cá 360° Không lo điểm mù

Model Parameters

ModelCS-CV346-A0-7A3WFR

Camera

Image Sensor1/2.8” Progressive Scan CMOS
Minimum Illumination0.01 lux @(F2.2,AGC ON), 0 lux with IR
Shutter SpeedSelf-adaptive shutter
Lens1.2mm@ F2.2, Horizontal angle: 180° Diagonal angle: 180°
Lens MountM12
Day & NightIR-cut filter with auto-switching
DNR3D DNR
WDRProgressive WDR

Compression

Video CompressionH.264
H.264 TypeMain profile
Video Bit RateHD, Balanced and Smooth. Adaptive bit rate


Max. Resolution1344×1344
Image settingBrightness, contrast, saturation, etc. (configurable via EZVIZ Studio)
BLCSupport

Network

StorageSupport Micro SD card (Max. 128G)
Smart AlarmMotion detection
Wi-Fi PairingSmartConfig (Wi-Fi One-Key Configuration)
ProtocolEZVIZ cloud proprietary protocol
Interface ProtocolEZVIZ cloud proprietary protocol
General FeaturesAnti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark
Minimum Network Requirements2Mbps

Wi-Fi

StandardIEEE802.11a/b/g/n/ac
Frequency Range2.412GHz ~ 2.462GHz/5.15GHz ~ 5.35GHz/ 5.725GHz ~ 5.825GHz
Channel BandwidthSupports 20MHz
SecurityWEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate11b: 11Mbps, 11g: 54Mbps, 11n: 135Mbps

General

Operating Conditions-10°C ~ 45°C, Humidity 95% or less (non-condensing)
Power SupplyDC 5V ±5%
Power ConsumptionMax. 8W
IR RangeMax. 7.5meters
Product Dimensions70mm x 70mm x 70.6mm
Packaging Dimensions109.5mm x 109.5mm x 123mm
Weight222g
