Mini Plus - Thiết bị siêu nhỏ, tính năng cực mạnh

Giá LH: 0869 525 552

Mini Plus - Thiết bị siêu nhỏ, tính năng cực mạnh

Giá LH: 0869 525 552

Thông số kỹ thuật

Mini Plus

Thiết bị siêu nhỏ, tính năng cực mạnh

Specifications

Model Parameters

ModelCS-CV200



Camera

Image Sensor1/2.7” Progressive Scan CMOS
Minimum Illumination0.02 lux @(F2.2, AGC ON), 0 lux with IR
Shutter Speed1/30s to 1/100,000s
Lens2.8mm @ F2.0 Horizontal angle: 116°, Diagonal angle: 135°
Lens MountM12
Day & NightIR-cut filter
DNR3D DNR
WDRHDR, Max. 120db
AudioBuilt-in Microphone and Speaker



Compression

Video CompressionH.264
H.264 TypeMain profile
Video Bit RateHi-Def, Standard and Basic. Adaptive bit rate.




Max. Resolution1920×1080

Network

StorageSupport Micro SD card (Max. 128G)
Smart AlarmSmart Motion detection
Wi-Fi PairingSmartConfig (Wi-Fi One-Key Configuration)
Interface ProtocolEZVIZ Cloud proprietary protocol
General FeaturesDual-Stream, Mirror Image
Minimum Network Requirements2Mbps



Wireless Specifications

StandardIEEE802.11b, 802.11g, 802.11n, 802.11ac
Frequency Range2.4GHz ~ 2.4835GHz/ 5.15GHz ~ 5.35GHz / 5.725GHz ~ 5.825GHz
Channel BandwidthSupports 20MHz
Security64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate802.11b: 11Mbps, 802.11g: 54Mbps, 802.11n: 150Mbps



General

Operating Conditions-10°C ~ 45°C, Humidity 95% or less (non-condensing)
Power SupplyDC 5V±10%
Power ConsumptionMax. 3.5W
IR RangeMax. 7.5 meters
Product Dimensions85mm x 52mm x 29mm
Packaging Dimensions148mm x 91.5mm x 85.5mm
Weight85.5 g
